Test how an encoder handles 4K video, with all aspects of global and local motion, slow/medium/fast motion, with panning, scrolling, rotation, smooth and erratic, high/low contrast, with limited colors/vivid colors and many common subject types. Scenes from USA (San Francisco, Las Vegas), Europe (UK) and Asia (S. Korea, Japan, China) at 4096x2304 res'n progressive and multiple frame rates: 59.94fps, 50.0fps, 23.976fps - with utility to convert to 29.97 / 25.0 fps, progressive or interlaced.
|Description||Scenes from USA (San Francisco, Las Vegas), Europe (UK) and Asia (S. Korea, Japan, China) at 4096x2304 resolution, progressive and multiple frame rates: 59.94fps, 50.0fps, 23.976fps - with utility to convert to 29.97 / 25.0 fps, progressive or interlaced|
|Purpose||Test how an encoder handles 4K video, with all aspects of global and local motion, slow/medium/fast motion, with panning, scrolling, rotation, smooth and erratic, high/low contrast, with limited colors/vivid colors and many common subject types|
4K (4096x2304, 4096x2160, 3840x2160). 59.94, 50, 29.97, 25, 23.976
10/12 bit YCbCr 4:2:2
|Audio Format||Wave (ucompressed PCM 48 kHz) and MPEG-1 Layer II stereo 384 kbps 16 bit 48 kHz|
|Number of Clips||20 individual video clips|
|Length of Video||12 minutes|
|Size on Disk||985 Gigabytes|
Why Choose TVids?
TVids were designed both for encoder users (broadcasters, post production, streaming) and for encoder developers, to provide full test coverage of just about any type of video feature that an encoder is likely to encounter, in sequences which you can freely use for demos, trade shows, and on your website.
Every TVid source was captured specifically to cover specific video situations that encoders will encounter. These situations were then codified in the manual and spreadsheet for each source. Both content (animals, people, buildings) and challenges (angles, banding, focus, panning, patterns) are listed for easy searching when detecting problems, or finding clips to challenge particular parts of the encoder.
All TVids were captured at the highest possible resolution, bit depth and frame rate. Lower resolution and frame rate versions were carefully created from the higher frame rate and resolution, providing the best possible quality. This also means the same tests can be made against equipment and software running at different frame rates and sizes (e.g. 1080, 720 and SD).
TVids provide the most complete suite of test video, that are uncompressed, high bit depth, high frame rate and well documented in the industry. TVids also provide a liberal multiple use in house and full use of exported/converted video and audio, with no worry about media and display rights internationally.
To get the most out of your TestVid test clips, TestVid has all the tools you need to display, convert and output your test material, test patterns and even other test material sources. All TestVid material is shipped in the highest possible quality, and can be read by a number of third party software products. These tools provide guaranteed high quality viewing and conversion to formats that are compatible with almost all off-the-shelf software.
TestVid Reactor is a dedicated tool that supports lossless conversion to uncompressed types and high quality conversion to compressed formats. Direct high bit depth YCbCr conversion from the original material to MOV, AVI, YUV, V210, DPX or MXF means every possible bit is preserved in a perfectly compatible format. Compressed outputs like XDCam, AVCi (optional), ProRes and DNxHD (optional) are also available for maximum display compatibility. Selectable timecode burn in and audio/video frame sync pulses adds further flexibility to the test media and test pattern output.
TestVid Pro Player
TestVid Pro Player provides 10 bit YCbCr to DVI, HDMI and HD-SDI using your AJA, BlueFish444 or Blackmagic video card, under Windows or OS-X. This player supports both the native, high bit depth raw file format or the test videos and patterns, as well as most standard scientific, post production and broadcast file formats. YUV, AVI, MOV, MXF, DPX, HDR/Raw and even MPEG-2, MPEG-4, h.264 and internet file types can be be played. Raw data (decimal/hex view), histogram, waveform monitors, vectorscope, and full screen DVI modes are included.
Special Limited Time Offer
For a limited time, both the TestVid Reactor and TestVid Pro Player are available bundled with any T2V (SD, HD, 2K and 4K test media) or T3D (3D 4K, 2K or HD) media set. One full feature license of both products will be included, with full support and updates for one year. Since we are including the TestVid Tools for free, if you need to license the AVCi and DNxHD codecs they are optional. Please note, this is a limited time offer.
Test Pattern Set - All TestVid test media packages include TestVid's Test Pattern set. The test pattern set includes over 100 test patterns for each video standard, including 4K, 2K, HD 1080, 720, SD PAL and SD NTSC. Audio files with calibrated Peak/RMS, EBU.128/1195 loudness, channel IDs and standard waveforms are also included. All patterns are 10 bit YCbCr frames, and up to 24 bit audio at 48000 Hz.
Test Pattern File Generator - Included with the test pattern source files is the TVid Test Pattern File Generator. This software allows the single frame patterns and audio to be combined into MXF, MOV, AVI and other standard files for use in testing, editing and calibration. The pattern files are also fully compatible with the included TestVid Pro Player for immediate HDMI, HD-SDI or DVI output, and TestVid Reactor for conversion to AVI, MOV, DPX, YUV, and MXF. This pattern system is also available separately for 99$ USD.
|Clip ID||Title||Main Purpose||Duration||Begin||End|
4K Progressive 60 FPS Numbers T2V041 0nn
|General codec test with complex scene and 'difficult' subjects including water, reflections with static background||
|T2V041002||Monorail||Straightforward codec efficiency test in reasonably complex scene||00:25:08|
|T2V041003||Night_travelator||Codec stress test with lots of moiré fringing and irregular movement||00:25:00|
|T2V041004||Pool_shark||'Codec nightmare', where motion vector tracking is extremely difficult||00:25:00|
|T2V041005||Ice_cream_van||Global motion with translation and rotation||00:25:00|
|T2V041006||Venetian_crossing||Complex scene as people walk towards camera||00:26:01|
|T2V041007||Fountain||Codec stress test with many similar reflective/transparent small areas||00:25:00|
4K Progressive 24 FPS Numbers T2V041 1nn
|T2V041111||Footbridge||Codec test when the moving subjects (the people) are substantially obscured, some of the time behind fine lines||01:01:18|
|T2V041112||Shopping_mall||Codec test with slow pan/scroll left/right in a highly contrasting scene with strong patterns||00:36:16|
|T2V041113||Ferry_arrives||Slow tracking of subject in largely static (complex) background but with water and obscuration||00:50:09|
|T2V041114||Cabot_Tower||Test with random movement (including rotation), irregular foreground (grass) man-made structure and largely monochrome blue sky||00:57:20|
|T2V041115||PedXing||Motion vector test, tracking people in a detailed scene||00:32:00|
|T2V041116||Waterfall||Largely static shot but sunlit waterfall makes motion vector tracking impossible on water||00:18:12|
|T2V041117||The_Matthew||Codec test with smooth scrolling and panning in complex scene||00:27:19|
4K Progressive 50 FPS Numbers T2Vo41 2nn
|T2V041221||Asakusa_man||Continuous random movement of background / subject tracking with foreground obscuration, and no global movement||00:24:16|
|T2V041222||Nippon_Express||Smooth panning motion left-wards, tracking a subject with continually varying obscuration and heat-haze causing continual minor movements of parts of the picture||00:44:00|
|T2V041223||Changing_the_guard||Codec efficiency test with scenes with limited movement, plus global translation, plus low brightness transition||00:27:22|
|T2V041224||Golden_statue||Codec efficiency test with scenes with limited movement, plus global translation, plus low brightness transition||00:26:11|
|T2V041225||Beijing_traffic||Codec efficiency test where scene changes from one where there is no global motion limited subject motion, to one where there is a global pan and zoom, plus continual subject movement||00:30:40|
|T2V041226||Fast_walk||Codec stress and efficiency test of grainy night scene with strong video effects applied||00:20:10|
T2V041 Demo Reel
(Note: Reduced resolution and compressed. Original
supplied files are full resolution and uncompressed)
|Clip Summary||Scene Features||User Manual Extract|
