3D Asia HD 1080
Test how an encoder handles 3D video, with all aspects of global and local motion, slow/medium/fast motion, with panning, scrolling, zooming, smooth and erratic, high/low contrast, with limited colors/vivid colors and many common subject types, plus different aspects of 3D (different negative & positive disparity, color & luma differences). Scenes from Japan, China and South Korea.
T3D007
|
2D/3D |
3D Stereoscopic |
|
Description |
Scenes from Asia (Japan, South Korea, China) at European frame rates |
|
Purpose |
Test how an encoder handles 3D video, with all aspects of global and local motion, slow/medium/fast motion, with panning, scrolling, zooming, smooth and erratic, high/low contrast, with limited colors/vivid colors and many common subject types, plus different aspects of 3D (different negative & positive disparity, color & luma differences) |
|
Video Format |
1080p:
1080i:
|
|
Audio Format |
MPEG-1 Layer II stereo 384kbps CBR 16-bit 48kHz and WAV linear PCM uncompressed stereo 1536kbps 48kHz |
|
Number of Clips |
70 Left & Right pairs of video clips (35 Left & Right pairs each at 1080p and 1080i) |
|
Length of Video |
Total of over 38 minutes (over 19 minutes each at 1080p and 1080i) |
|
Size on Disk |
535GBytes |
Why Choose TVids?
TVids were designed both for encoder users (broadcasters, post production, streaming) and for encoder developers, to provide full test coverage of just about any type of video feature that an encoder is likely to encounter, in sequences which you can freely use for demos, trade shows, and on your website.
Every TVid source was captured specifically to cover specific video situations that encoders will encounter. These situations were then codified in the manual and spreadsheet for each source. Both content (animals, people, buildings) and challenges (angles, banding, focus, panning, patterns) are listed for easy searching when detecting problems, or finding clips to challenge particular parts of the encoder.
All TVids were captured at the highest possible resolution, bit depth and frame rate. Lower resolution and frame rate versions were carefully created from the higher frame rate and resolution, providing the best possible quality. This also means the same tests can be made against equipment and software running at different frame rates and sizes (e.g. 1080, 720 and SD).
TVids provide the most complete suite of test video, that are uncompressed, high bit depth, high frame rate and well documented in the industry. TVids also provide a liberal multiple use in house and full use of exported/converted video and audio, with no worry about media and display rights internationally.
TestVid Tools
To get the most out of your TestVid test clips, TestVid has all the tools you need to display, convert and output your test material, test patterns and even other test material sources. All TestVid material is shipped in the highest possible quality, and can be read by a number of third party software products. These tools provide guaranteed high quality viewing and conversion to formats that are compatible with almost all off-the-shelf software.
TestVid Reactor
TestVid Reactor is a dedicated tool that supports lossless conversion to uncompressed types and high quality conversion to compressed formats. Direct high bit depth YCbCr conversion from the original material to MOV, AVI, YUV, V210, DPX or MXF means every possible bit is preserved in a perfectly compatible format. Compressed outputs like XDCam, AVCi (optional), ProRes and DNxHD (optional) are also available for maximum display compatibility. Selectable timecode burn in and audio/video frame sync pulses adds further flexibility to the test media and test pattern output.
For more information, click here.
TestVid Pro Player
TestVid Pro Player provides 10 bit YCbCr to DVI, HDMI and HD-SDI using your AJA, BlueFish444 or Blackmagic video card, under Windows or OS-X. This player supports both the native, high bit depth raw file format or the test videos and patterns, as well as most standard scientific, post production and broadcast file formats. YUV, AVI, MOV, MXF, DPX, HDR/Raw and even MPEG-2, MPEG-4, h.264 and internet file types can be be played. Raw data (decimal/hex view), histogram, waveform monitors, vectorscope, and full screen DVI modes are included.
For more information, click here.
Special Limited Time Offer
For a limited time, both the TestVid Reactor and TestVid Pro Player are available bundled with any T2V (SD, HD, 2K and 4K test media) or T3D (3D 4K, 2K or HD) media set. One full feature license of both products will be included, with full support and updates for one year. Since we are including the TestVid Tools for free, if you need to license the AVCi and DNxHD codecs they are optional. Please note, this is a limited time offer.
TestVid Extras
Test Pattern Set - All TestVid test media packages include TestVid's Test Pattern set. The test pattern set includes over 100 test patterns for each video standard, including 4K, 2K, HD 1080, 720, SD PAL and SD NTSC. Audio files with calibrated Peak/RMS, EBU.128/1195 loudness, channel IDs and standard waveforms are also included. All patterns are 10 bit YCbCr frames, and up to 24 bit audio at 48000 Hz.
Test Pattern File Generator - Included with the test pattern source files is the TVid Test Pattern File Generator. This software allows the single frame patterns and audio to be combined into MXF, MOV, AVI and other standard files for use in testing, editing and calibration. The pattern files are also fully compatible with the included TestVid Pro Player for immediate HDMI, HD-SDI or DVI output, and TestVid Reactor for conversion to AVI, MOV, DPX, YUV, and MXF. This pattern system is also available separately for 99$ USD.
Clip Summary
| Clip ID | Title | Main Purpose | Duration | Begin | End |
|---|---|---|---|---|---|
|
T3D007001 |
Asakusa_man |
Continuous random movement of background, with foreground obscuration, and no global movement |
00:23:41, 00:23:20 |
 |
 |
|
T3D007002 |
Seoul_shower |
Codec stress and efficiency test with multiple small changes (due to raindrops) |
00:43:36, 00:43:18 |
 |
 |
|
T3D007003 |
Nippon_Express |
Smooth panning motion leftwards, tracking a main subject with continually varying obscuration and heat-haze causing continual minor movements of parts of the picture |
00:57:19, 00:57:09 |
 |
 |
|
T3D007004 |
Masked_dance |
Codec efficiency with highly colored subject moving randomly against a patterned background, with out-of focus transition and camera flashes |
00:30:40, 00:30:20 |
 |
 |
|
T3D007005 |
Train_ride |
Tough combined codec stress test with random rotational global motion with zoom, many line objects, patterns, graininess, high & low contrast areas, obscuration, foreground reflections & spots, brightness changes and a complex scene with a jump cut |
00:30:36, 00:30:18 |
 |
 |
|
T3D007006 |
Changing_the_guard |
Codec efficiency test with scenes with limited movement, plus global translation, plus dip-to-black fades |
00:47:22, 00:47:11 |
 |
 |
|
T3D007007 |
Balustrades |
Codec stress test with relatively large subjects being frequently obscured by highly patterned objects (no global motion) |
00:25:24, 00:25:12 |
 |
 |
|
T3D007008 |
Green_scene |
Efficiency test with scene comprising detailed natural objects and water, with continuous (generally) smooth translation |
00:32:00, 00:32:00 |
 |
 |
|
T3D007009 |
Souvenir_shops |
Motion vector tracking of many subjects moving in different directions, with continual random lateral and rotational motion |
00:49:44, 00:49:22 |
 |
 |
|
T3D007010 |
Rooves |
Codec test of motion vector tracking with slow pan left and right of many similarly highly-patterned objects |
00:35:22, 00:35:11 |
 |
 |
|
T3D007011 |
Dancing_girls |
Codec efficiency test in scene where camera gain high due to relatively low light indoors (and consequently some camera artefacts) |
00:31:26, 00:31:13 |
 |
 |
|
T3D007012 |
Takeshita_street |
Slow non-uniform vertical translation and zoom, with many subjects and obscuration |
00:23:02, 00:23:01 |
 |
 |
|
T3D007013 |
Shipyard_cranes |
Codec stress test with very rapid movement of foreground blurred objects obscuring detailed subjects in the background, also moving relatively |
00:38:09, 00:38:04 |
 |
 |
|
T3D007014 |
Fast_walk |
Codec stress and efficiency test of grainy night scene with video effects applied |
00:20:10, 00:20:05 |
 |
 |
|
T3D007015 |
Skyscrapers |
Continuous rotational movement test of relatively simple scene but with highly patterned low-contrast buildings |
00:32:41, 00:32:20 |
 |
 |
|
T3D007016 |
Pavement_patterns |
Global motion tracking with highly patterned background providing a codec stress test |
00:32:42, 00:32:21 |
 |
 |
|
T3D007017 |
Bullet_train |
Stress test with white fade-in and fade-out, white fade in the middle, and rapid direction changes |
00:21:42, 00:21:21 |
 |
 |
|
T3D007018 |
Great_Wall |
Efficiency test with patterns and random global rotational movement, slow cross fade and global non-smooth pan/scroll |
01:19:20, 01:19:10 |
 |
 |
|
T3D007019 |
Beijing_traffic |
Codec efficiency test where scene changes from one where there is no global motion & limited subject motion, to one where there is a global pan and zoom, plus continual subject movement |
00:42:32, 00:42:16 |
 |
 |
|
T3D007020 |
Night_neon |
Nighttime test with high contrast and slow global scroll upwards |
00:20:34, 00:20:17 |
 |
 |
|
T3D007021 |
Dragon_river |
Efficiency test with global movement into the scene, with reflections, multiple moving subjects, irregular global motion & continuous haze (on distant hills) |
00:28:30, 00:28:15 |
 |
 |
|
T3D007022 |
Disappear |
Motion vector stress test where almost all of image is similar and low contrast, plus check id codec produces banding on output |
00:25:01, 00:25:00 |
 |
 |
|
T3D007023 |
Shibuya_spin |
Rapid left pan with some rotational movement, with many subjects crossing the picture |
00:23:26, 00:23:13 |
 |
 |
|
T3D007024 |
Shopping_mall |
Frequent v. small up/down global movement and background colored light changes with continuous random movement of large and obscured subjects |
00:41:14, 00:41:07 |
 |
 |
|
T3D007025 |
Star_ferry |
Codec tracking efficiency of main subject largely stationary in field of view, with continual relative movement of a complex background |
00:30:00, 00:30:00 |
 |
 |
|
T3D007026 |
Duck_man |
Motion vector/efficiency test at jump cuts and because we liked the audio! |
00:28:44, 00:28:22 |
 |
 |
|
T3D007027 |
Golden_statue |
Smooth panning motion rightwards with a few irregular global movements |
00:26:11, 00:26:05 |
 |
 |
|
T3D007028 |
Hazy_HK |
Codec efficiency and stress test with low-contrast detailed scene (and very strong moire fringes on one building) |
00:16:35, 00:16:17 |
 |
 |
|
T3D007029 |
Escalator |
Test with dark scene, areas of grain and high contrast, with slow global right-wards translation |
00:20:28, 00:20:14 |
 |
 |
|
T3D007030 |
Yangshuo_dusk |
Stress test with high contrast scene and non-smooth global pan |
00:09:40, 00:09:20 |
 |
 |
|
T3D007031 |
Harbour_night |
Codec stress test with worst grain ever likely to encounter (e.g. from a nightcam), fine subjects and high contrast |
00:21:14, 00:21:07 |
 |
 |
|
T3D007032 |
PedXing_below |
Motion vector tracking of many objects (people) primarily moving horizontally or vertically, then global motion track |
00:34:08, 00:34:04 |
 |
 |
|
T3D007033 |
Terracotta_warriors |
Efficiency test where there is no subject movement but continual zoom, translation, high camera noise (due to low light) and shimmering due to non-synchronized lighting in a low contrast monochromatic scene |
00:58:02, 00:58:01 |
 |
 |
|
T3D007034 |
Forbidden_City |
Codec efficiency tracking many subjects moving principally left/right but other directions, many of which small in field of view |
00:21:40, 00:21:20 |
 |
 |
|
T3D007035 |
Sideways |
Efficiency and stress tests with non-standard view (rotated 90 degrees) where translation is not in usual direction |
00:41:02 00:41:01 |
 |
 |
3D Show Reel
This show reel is 3D anaglyph flash compressed to 2 mbit at 854x574, and should not be used to judge the quality of the source material.
 |
 |
 |
