HD 1080 720 Asia

hD 128
Test how an encoder handles all aspects of global and local motion, slow/medium/fast motion, with panning, scrolling, zooming, smooth and erratic, high/low contrast, with limited colors/vivid colurs and many common subject types. Scenes from Asia (S. Korea, Japan, China) at European frame rates, including, HD and SD at 50.0 / 25.0 fps, progressive and interlaced.

T2V027



2D/3D 2D
Description Scenes from Asia (S. Korea - Seoul; Japan - Tokyo and Kyoto; China - Beijing, Xi'an, Yangshuo, Hong Kong) at European frame rates, including, HD and SD at 50.0 / 25.0 fps, progressive and interlaced.
Purpose Test how an encoder handles all aspects of global and local motion, slow/medium/fast motion, with panning, scrolling, zooming, smooth and erratic, high/low contrast, with limited colors/vivid colors and many common subject types
Video Format

Format                                  Frame          Interlaced
number        Resolution            rate            / progressive

    0             1920x1080           25.0            Progressive

    1             1280x720             25.0            Interlaced Top Field First

    2              720x576              50.0            Progressive

    3              720x576              25.0            Progressive

    4              720x480              50.0            Progressive

    5              720x480              25.0            Progressive

    6              720x480              25.0            Interlaced Top Field First

    7              720x480              25.0            Interlaced Bottom Field First

All YUV planar, 4:2:0, 8-bits per component
Audio Format

MPEG-1 Layer II stereo 384kbps CBR 16-bit 48kHz and

WAV linear PCM uncompressed stereo 1536kbps 48kHz
Number of Clips 280 individual video clips (35 at each resolution)
Length of Video Total of 2 hours 32 minutes (just over 19 minutes at each resolution)
Size on Disk 387 GBytes



Why Choose TVids?

TVids were designed both for encoder users (broadcasters, post production, streaming) and for encoder developers, to provide full test coverage of just about any type of video feature that an encoder is likely to encounter, in sequences which you can freely use for demos, trade shows, and on your website.

Every TVid source was captured specifically to cover specific video situations that encoders will encounter.  These situations were then codified in the manual and spreadsheet for each source.  Both content (animals, people, buildings) and challenges (angles, banding, focus, panning, patterns) are listed for easy searching when detecting problems, or finding clips to challenge particular parts of the encoder.

All TVids were captured at the highest possible resolution, bit depth and frame rate.  Lower resolution and frame rate versions were carefully created from the higher frame rate and resolution, providing the best possible quality.  This also means the same tests can be made against equipment and software running at different frame rates and sizes (e.g. 1080, 720 and SD).

TVids provide the most complete suite of test video, that are uncompressed, high bit depth, high frame rate and well documented in the industry.  TVids also provide a liberal multiple use in house and full use of exported/converted video and audio, with no worry about media and display rights internationally.

TestVid Tools

To get the most out of your TestVid test clips, TestVid has all the tools you need to display, convert and output your test material, test patterns and even other test material sources.  All TestVid material is shipped in the highest possible quality, and can be read by a number of third party software products. These tools provide guaranteed high quality viewing and conversion to formats that are compatible with almost all off-the-shelf software.

TestVid Reactor

TestVid Reactor is a dedicated tool that supports lossless conversion to uncompressed types and high quality conversion to compressed formats.  Direct high bit depth YCbCr conversion from the original material to MOV, AVI, YUV, V210, DPX or MXF means every possible bit is preserved in a perfectly compatible format. Compressed outputs like XDCam, AVCi (optional), ProRes and DNxHD (optional) are also available for maximum display compatibility.  Selectable timecode burn in and audio/video frame sync pulses adds further flexibility to the test media and test pattern output.

For more information, click here.

TestVid Pro Player

TestVid Pro Player provides 10 bit YCbCr to DVI, HDMI and HD-SDI using your AJA, BlueFish444 or Blackmagic video card, under Windows or OS-X. This player supports both the native, high bit depth raw file format or the test videos and patterns, as well as most standard scientific, post production and broadcast file formats.  YUV, AVI, MOV, MXF, DPX, HDR/Raw and even MPEG-2, MPEG-4, h.264 and internet file types can be be played.  Raw data (decimal/hex view), histogram, waveform monitors, vectorscope, and full screen DVI modes are included.

For more information, click here.

Special Limited Time Offer

For a limited time, both the TestVid Reactor and TestVid Pro Player are available bundled with any T2V (SD, HD, 2K and 4K test media) or T3D (3D 4K, 2K or HD) media set.  One full feature license of both products will be included, with full support and updates for one year.  Since we are including the TestVid Tools for free, if you need to license the AVCi and DNxHD codecs they are optional. Please note, this is a limited time offer.

TestVid Extras

Test Pattern Set - All TestVid test media packages include TestVid's Test Pattern set.  The test pattern set includes over 100 test patterns for each video standard, including 4K, 2K, HD 1080, 720, SD PAL and SD NTSC.  Audio files with calibrated Peak/RMS, EBU.128/1195 loudness, channel IDs and standard waveforms are also included.  All patterns are 10 bit YCbCr frames, and up to 24 bit audio at 48000 Hz.

Test Pattern File Generator - Included with the test pattern source files is the TVid Test Pattern File Generator.  This software allows the single frame patterns and audio to be combined into MXF, MOV, AVI and other standard files for use in testing, editing and calibration.  The pattern files are also fully compatible with the included TestVid Pro Player for immediate HDMI, HD-SDI or DVI output, and TestVid Reactor for conversion to AVI, MOV, DPX, YUV, and MXF. This pattern system is also available separately for 99$ USD.

Clip Summary

Clip IDTitleMain PurposeDurationBeginEnd

T2V027n01

Asakusa_man

Continuous random movement of background, with foreground obscuration, and no global movement

1,191 (50p)
595 (25i)
595 (25p)



T2V027n02

Seoul_shower

Codec stress and efficiency test with multiple small changes (due to raindrops)

2,186 (50p)
1,093 (25i)
1,093 (25p)



T2V027n03

Nippon_Express

Smooth panning motion left-wards, tracking a main subject with continually varying obscuration and heat-haze causing continual minor movements of parts of the picture

2,869 (50p)
1,434 (25i)
1,435 (25p)



T2V027n04

Masked_dance

Codec efficiency with highly colored subject moving randomly against a patterned background, with out-of focus transition and camera flashes

1,540 (50p)
770 (25i)
770 (25p)



T2V027n05

Train_ride

Tough combined codec stress test with random rotational global motion with zoom, many line objects, patterns, graininess, high & low contrast areas, obscuration, foreground reflections & spots, brightness changes and a complex scene with a jump cut

1,536 (50p)
768 (25i)
768 (25p)



T2V027n06

Changing_the_guard

Codec efficiency test with scenes with limited movement, plus global translation, plus dip-to-black fades

2,372 (50p)
1,186 (25i)
1,186 (25p)



T2V027n07

Balustrades

Codec stress test with relatively large subjects being frequently obscured by highly patterned objects (no global motion)

1,274 (50p)
637 (25i)
637 (25p)



T2V027n08

Green_scene

Efficiency test with scene comprising detailed natural objects and water, with continuous (generally) smooth translation

1,600 (50p)
800 (25i)
800 (25p)



T2V027n09

Souvenir_shops

Motion vector tracking of many subjects moving in different directions, with continual random lateral and rotational motion

2,494 (50p)
1,247 (25i)
1,247 (25p)



T2V027n10

Rooves

Codec test of motion vector tracking with slow pan left and right of many similarly highly-patterned objects

1,772 (50p)
886 (25i)
886 (25p)



T2V027n11

Dancing_girls

Codec efficiency test in scene where camera gain high due to relatively low light indoors (and consequently some camera artefacts)

1,576 (50p)
788 (25i)
788 (25p)



T2V027n12

Takeshita_street

Slow non-uniform vertical translation and zoom, with many subjects and obscuration

1,152 (50p)
576 (25i)
576 (25p)



T2V027n13

Shipyard_cranes

Codec stress test with very rapid movement of foreground blurred objects obscuring detailed subjects in the background, also moving relatively

1,909 (50p)
954 (25i)
955 (25p)



T2V027n14

Fast_walk

Codec stress and efficiency test of grainy night scene with video effects applied

1,010 (50p)
505 (25i)
505 (25p)



T2V027n15

Skyscrapers

Continuous rotational movement test of relatively simple scene but with highly patterned low-contrast buildings

1,641 (50p)
820 (25i)
821 (25p)



T2V027n16

Pavement_patterns

Global motion tracking with highly patterned background providing a codec stress test

1,642 (50p)
821 (25i)
821 (25p)



T2V027n17

Bullet_train

Stress test with white fade-in and fade-out, white fade in the middle, and rapid direction changes

1,092 (50p)
546 (25i)
546 (25p)



T2V027n18

Great_Wall

Efficiency test with patterns and random global rotational movement, slow cross fade and global non-smooth pan/scroll

3,970 (50p)
1,985 (25i)
1,985 (25p)



T2V027n19

Beijing_traffic

Codec efficiency test where scene changes from one where there is no global motion & limited subject motion, to one where there is a global pan and zoom, plus continual subject movement

2,132 (50p)
1,066 (25i)
1,066 (25p)



T2V027n20

Night_neon

Night-time test with high contrast and slow global scroll upwards

1,034 (50p)
517 (25i)
517 (25p)



T2V027n21

Dragon_river

Efficiency test with global movement into the scene, with reflections, multiple moving subjects, irregular global motion & continuous haze (on distant hills)

1,430 (50p)
715 (25i)
715 (25p)



T2V027n22

Disappear

Motion vector stress test where almost all of image is similar and low contrast, plus check id codec produces banding on output

1,251 (50p)
625 (25i)
626 (25p)



T2V027n23

Shibuya_spin

Rapid left pan with some rotational movement, with many subjects crossing the picture

1,176 (50p)
588 (25i)
588 (25p)



T2V027n24

Shopping_mall

Frequent v. small up/down global movement and background colored light changes with continuous random movement of large and obscured subjects

2,064 (50p)
1,032 (25i)
1,032 (25p)



T2V027n25

Star_ferry

Codec tracking efficiency of main subject largely stationary in field of view, with continual relative movement of a complex background

1,500 (50p)
750 (25i)
750 (25p)



T2V027n26

Duck_man

Motion vector/efficiency test at jump cuts and because we liked the audio !

1,444 (50p)
722 (25i)
722 (25p)



T2V027n27

Golden_statue

Smooth panning motion right-wards with a few irregular global movements

1,311 (50p)
655 (25i)
656 (25p)



T2V027n28

Hazy_HK

Codec efficiency and stress test with low-contrast detailed scene (and very strong moire fringes on one building)

835 (50p)
417 (25i)
418 (25p)



T2V027n29

Escalator

Test with dark scene, areas of grain and high contrast, with slow global right-wards translation

1,028 (50p)
514 (25i)
514 (25p)



T2V027n30

Yangshuo_dusk

Stress test with high contrast scene and non-smooth global pan

490 (50p)
245 (25i)
245 (25p)



T2V027n31

Harbour_night

Codec stress test with worst grain ever likely to encounter (e.g. from a nightcam), fine subjects and high contrast

1,064 (50p)
532 (25i)
532 (25p)



T2V027n32

PedXing_below

Motion vector tracking of many objects (people) primarily moving horizontally or vertically, then global motion track

1,708 (50p)
854 (25i)
854 (25p)



T2V027n33

Terracotta_warriors

Efficiency test where there is no subject movement but continual zoom, translation, high camera noise (due to low light) and shimmering due to non-synchronized lighting in a low contrast mono-color scene

2,902 (50p)
1,451 (25i)
1,451 (25p)



T2V027n34

Forbidden_City

Codec efficiency tracking many subjects moving principally left/right but other directions, many of which small in field of view

1,090 (50p)
545 (25i)
545 (25p)



T2V027n35

Sideways

Efficiency and stress tests with non-standard view (rotated 90 degrees) where translation is not in usual direction

2,052 (50p)
1,026 (25i)
1,026 (25p)







T2V027 Demo Reel

(Note: Reduced resolution and compressed.  Original

supplied files are full resolution and uncompressed)
