Low Res Test Media
Test how an encoder handles lower resolution video (D1PAL and below; web-sized), in all aspects of global and local motion, slow/medium/fast motion, with panning, scrolling, zooming, smooth and erratic, high/low contrast, with limited colors/vivid colors and many common subject types. Scenes from Europe (London, Barcelona, Bruges, Munich) and USA (New York, San Francisco, Las Vegas).
T2V004
| 2D/3D |
2D |
|||||||||||||||||||||||||||||||||||||||||||||||||
| Description |
Scenes from Europe (London, Barcelona, Bruges, Munich) and USA (New York, San Francisco, Las Vegas) |
|||||||||||||||||||||||||||||||||||||||||||||||||
| Purpose |
Test how an encoder handles lower resolution video (D1PAL and below; web-sized), in all aspects of global and local motion, slow/medium/fast motion, with panning, scrolling, zooming, smooth and erratic, high/low contrast, with limited colors/vivid colors and many common subject types |
|||||||||||||||||||||||||||||||||||||||||||||||||
| Video Format |
YUV 4:2:0 planar 8 bits per sample [originally filmed at 25 fps]
|
|||||||||||||||||||||||||||||||||||||||||||||||||
| Audio Format |
MPEG-1 Layer II stereo 384kbps CBR 16-bit 48kHz and WAV linear PCM uncompressed stereo 1536kbps 48kHz |
|||||||||||||||||||||||||||||||||||||||||||||||||
| Number of Clips |
840 individual video clips: 70 at each resolution |
|||||||||||||||||||||||||||||||||||||||||||||||||
| Length of Video |
Total of over 9 hours 52 minutes (over 49 minutes each at 1080p, 720p and 1080i resolutions) |
|||||||||||||||||||||||||||||||||||||||||||||||||
| Size on Disk |
179 GBytes |
Why Choose TVids?
TVids were designed both for encoder users (broadcasters, post production, streaming) and for encoder developers, to provide full test coverage of just about any type of video feature that an encoder is likely to encounter, in sequences which you can freely use for demos, trade shows, and on your website.
Every TVid source was captured specifically to cover specific video situations that encoders will encounter. These situations were then codified in the manual and spreadsheet for each source. Both content (animals, people, buildings) and challenges (angles, banding, focus, panning, patterns) are listed for easy searching when detecting problems, or finding clips to challenge particular parts of the encoder.
All TVids were captured at the highest possible resolution, bit depth and frame rate. Lower resolution and frame rate versions were carefully created from the higher frame rate and resolution, providing the best possible quality. This also means the same tests can be made against equipment and software running at different frame rates and sizes (e.g. 1080, 720 and SD).
TVids provide the most complete suite of test video, that are uncompressed, high bit depth, high frame rate and well documented in the industry. TVids also provide a liberal multiple use in house and full use of exported/converted video and audio, with no worry about media and display rights internationally.
TestVid Tools
To get the most out of your TestVid test clips, TestVid has all the tools you need to display, convert and output your test material, test patterns and even other test material sources. All TestVid material is shipped in the highest possible quality, and can be read by a number of third party software products. These tools provide guaranteed high quality viewing and conversion to formats that are compatible with almost all off-the-shelf software.
TestVid Reactor
TestVid Reactor is a dedicated tool that supports lossless conversion to uncompressed types and high quality conversion to compressed formats. Direct high bit depth YCbCr conversion from the original material to MOV, AVI, YUV, V210, DPX or MXF means every possible bit is preserved in a perfectly compatible format. Compressed outputs like XDCam, AVCi (optional), ProRes and DNxHD (optional) are also available for maximum display compatibility. Selectable timecode burn in and audio/video frame sync pulses adds further flexibility to the test media and test pattern output.
For more information, click here.
TestVid Pro Player
TestVid Pro Player provides 10 bit YCbCr to DVI, HDMI and HD-SDI using your AJA, BlueFish444 or Blackmagic video card, under Windows or OS-X. This player supports both the native, high bit depth raw file format or the test videos and patterns, as well as most standard scientific, post production and broadcast file formats. YUV, AVI, MOV, MXF, DPX, HDR/Raw and even MPEG-2, MPEG-4, h.264 and internet file types can be be played. Raw data (decimal/hex view), histogram, waveform monitors, vectorscope, and full screen DVI modes are included.
For more information, click here.
Special Limited Time Offer
For a limited time, both the TestVid Reactor and TestVid Pro Player are available bundled with any T2V (SD, HD, 2K and 4K test media) or T3D (3D 4K, 2K or HD) media set. One full feature license of both products will be included, with full support and updates for one year. Since we are including the TestVid Tools for free, if you need to license the AVCi and DNxHD codecs they are optional. Please note, this is a limited time offer.
TestVid Extras
Test Pattern Set - All TestVid test media packages include TestVid's Test Pattern set. The test pattern set includes over 100 test patterns for each video standard, including 4K, 2K, HD 1080, 720, SD PAL and SD NTSC. Audio files with calibrated Peak/RMS, EBU.128/1195 loudness, channel IDs and standard waveforms are also included. All patterns are 10 bit YCbCr frames, and up to 24 bit audio at 48000 Hz.
Test Pattern File Generator - Included with the test pattern source files is the TVid Test Pattern File Generator. This software allows the single frame patterns and audio to be combined into MXF, MOV, AVI and other standard files for use in testing, editing and calibration. The pattern files are also fully compatible with the included TestVid Pro Player for immediate HDMI, HD-SDI or DVI output, and TestVid Reactor for conversion to AVI, MOV, DPX, YUV, and MXF. This pattern system is also available separately for 99$ USD.
Clip Summary
| Clip ID | Title | Main Purpose | Duration | Begin | End |
|---|---|---|---|---|---|
|
T2V004nn01 |
Bars countdown |
Monitor set up; text |
00:50:00 |
 |
 |
|
T2V004nn02 |
Big Ben |
Rapid motion tracking and linear detail patterns with bright colors and large monochromatic areas |
00:17:13 |
 |
 |
|
T2V004nn03 |
Red leaves |
Shallow focus on detailed natural patterns and irregular global motion |
01:01:24 |
 |
 |
|
T2V004nn04 |
Priest |
Compression of facial features with objects passing behind and in front |
00:49:06 |
 |
 |
|
T2V004nn05 |
Eye pod |
Slow global motion with high contrast |
02:23:18 |
 |
 |
|
T2V004nn06 |
Angled ride |
Fast global motion |
00:29:00 |
 |
 |
|
T2V004nn07 |
Duckman |
Compression of bright and rounded features with quick movement |
00:47:19 |
 |
 |
|
T2V004nn08 |
Green weed |
Macroblock motion vectors in high contrast image, with small particles in front of objects |
00:34:04 |
 |
 |
|
T2V004nn09 |
Neon tunnel |
Medium speed leftwards global motion with rapid irregular motion and bright changing colors |
01:05:16 |
 |
 |
|
T2V004nn10 |
Pidgeon bully |
Compression of fur-like detailed features with shallow focus |
00:39:21 |
 |
 |
|
T2V004nn11 |
Red white crane |
Rapid global and macroblock motion vector tracking behind objects |
00:22:04 |
 |
 |
|
T2V004nn12 |
Raindrops |
Irregular random objects (raindrops) with patterns and fine detail |
00:32:07 |
 |
 |
|
T2V004nn13 |
Polizia |
Text and people compression with limited then rapid global motion and macroblock motion vector tracking |
01:31:09 |
 |
 |
|
T2V004nn14 |
Beer festival |
High contrast early evening images with some very bright and some dark grainy images with people |
00:31:15 |
 |
 |
|
T2V004nn15 |
Mind the wall |
Compression of very rapidly moving patterns (rapid but consistent global motion and macroblock motion vectors) |
00:21:04 |
 |
 |
|
T2V004nn16 |
Little girl |
Random but relatively slow global motion with zoom in and tracking person with people obscuring view |
00:51:11 |
 |
 |
|
T2V004nn17 |
Flower focus |
Brightly sunlit natural patterns with focus shifting and zoom out |
01:14:02 |
 |
 |
|
T2V004nn18 |
Bike woman |
Medium speed tracking of motion vectors with frequently obscured subject and opposite direction global motion in highly patterned image |
00:32:11 |
 |
 |
|
T2V004nn19 |
Cargo boat |
Tracking linear object moving on water with round and detailed pattern objects in background |
00:43:09 |
 |
 |
|
T2V004nn20 |
Globes |
Slow global zoom out with round objects and rapidly changing focus |
00:18:16 |
 |
 |
|
T2V004nn21 |
Lion fish |
Motion vector tracking slow moving natural high-contrast patterns |
01:01:12 |
 |
 |
|
T2V004nn22 |
Nelsons monument |
Slow global scroll down with irregular shapes and patterns and irregular small global movement |
00:25:19 |
 |
 |
|
T2V004nn23 |
Lit fountains |
High contrast indistinct objects (water) rapidly changing position and color in grainy image |
01:18:00 |
 |
 |
|
T2V004nn24 |
Clock tower |
Macroblock motion vectors of identical mirrored areas with detail but monochromatic background |
00:10:17 |
 |
 |
|
T2V004nn25 |
Vatican traffic |
Complex scene with multiple objects for motion vector tracking, with scene jump |
00:21:17 |
 |
 |
|
T2V004nn26 |
Water up |
High contrast image macroblock motion vector tracking with random angled motion |
00:25:11 |
 |
 |
|
T2V004nn27 |
Sky clouds |
Slow uniform global motion and macroblock tracking of indistinct irregular shapes |
01:03:06 |
 |
 |
|
T2V004nn28 |
Times Square |
Global motion of frame to the right with some fast-moving objects in opposite direction |
00:29:14 |
 |
 |
|
T2V004nn29 |
Chrysler building |
Global zoom of low-contrast complex scene with many fine lines and detail |
00:38:13 |
 |
 |
|
T2V004nn30 |
Display |
Rapidly changing scene on display, with high-contrast |
00:21:10 |
 |
 |
|
T2V004nn31 |
Smiling |
Compression of faces, some in and some out of focus |
00:19:17 |
 |
 |
|
T2V004nn32 |
Traffic duty |
Compression of people with many movements and some obscuration |
00:32:19 |
 |
 |
|
T2V004nn33 |
Empire State |
Global motion scrolling up with fine lines, patterns and angles |
00:57:17 |
 |
 |
|
T2V004nn34 |
Checked caps |
Motion vectors of multiple people moving semi-randomly with some obscuration and out-of-focus |
00:21:19 |
 |
 |
|
T2V004nn35 |
Gold statue |
Compression of water and largely monochromatic object but which has round and other patterns |
00:49:07 |
 |
 |
|
T2V004nn36 |
Eyewitness news |
Compression of rapidly moving text |
00:13:06 |  |
 |
|
T2V004nn37 |
Buggy ride |
Tracking of large object in foreground moving across detailed background |
00:40:00 |  |
 |
|
T2V004nn38 |
Couple talking | Efficiency check dealing with scene with low movement but fine-detailed background | 01:00:09 |  |
 |
|
T2V004nn39 |
86th floor | Global motion of pseudo-ransom movement of whole scene, then global zoom out in addition | 00:35:21 |  |
 |
|
T2V004nn40 |
Please tell | Compression of screen dots/potential moire fringing | 00:36:16 |  |
 |
|
T2V004nn41 |
Traffic twds | Motion vectors of multiple objects growing larger | 00:12:16 |  |
 |
|
T2V004nn42 |
NY rant | Efficient compression of talking head foreground and multiple objects moving in background | 00:53:08 |  |
 |
|
T2V004nn43 |
Grey buildings | Compression of patterns and lines in visually flat areas (test ringing artefacts around lines) | 00:30:03 |  |
 |
|
T2V004nn44 |
Blue coat | Efficiency of talking heads compression with movement and increasing size | 00:24:13 |  |
 |
|
T2V004nn45 |
People crossing | Motion vectors of many objects and people of different sizes moving in different directions | 00:35:18 |  |
 |
|
T2V004nn46 |
Pan left | Tracking of large object filling image then across detailed scene including text then tracking multiple objects (people) | 00:31:23 |  |
 |
|
T2V004nn47 |
Washington Circle | Circular global motion of high contrast but largely monochromatic objects with patterns | 00:18:16 |  |
 |
|
T2V004nn48 |
Running backwards | Compression of scene played backwards | 00:25:05 |  |
 |
|
T2V004nn49 |
Following | Compression of highly random movement with highlights on large dark area | 00:24:23 |  |
 |
|
T2V004nn50 |
Times Sq night | High contrast with multiple very dark areas and very bright areas | 00:26:11 |  |
 |
|
T2V004nn51 |
Evening cabs | Night-time scene with many reflective objects mainly getting smaller | 00:43:11 |  |
 |
|
T2V004nn52 |
Football game | Motion vectors of objects (people) moving in random directions with pattern and detail (grass) behind | 00:56:22 |  |
 |
|
T2V004nn53 |
Coney Island | Text compression and tracking of object (man) in busy scene with largely monochromatic but detailed area (sand) | 00:32:21 |  |
 |
|
T2V004nn54 |
Hazy crowd | Motion vectors of very large number of objects (people) in low-contrast scene | 00:31:08 |  |
 |
|
T2V004nn55 |
Dizzy dragons | Compression of large high contrast rapidly moving areas (mainly monochromatic), with frequent obscuration | 01:05:21 |  |
 |
|
T2V004nn56 |
Turnpike | Motion vectors of small objects moving fast, diagonally, where intermediate frames have been removed | 00:52:11 |  |
 |
|
T2V004nn57 |
Enjoy the adventure | Slow global motion & slow zoom | 00:47:19 |  |
 |
|
T2V004nn58 |
Pier 39 shops | Medium speed macroblock motion vectors | 01:08:16 |  |
 |
|
T2V004nn59 |
Close up carousel | Fast macroblock motion vectors with obscured objects | 00:15:11 |  |
 |
|
T2V004nn60 |
Golden evening | Slow global zoom in high contrast with fine lines and out-of-focus | 02:27:15 |  |
 |
|
T2V004nn61 |
Waiting in line | Global motion around focus point | 00:52:08 |  |
 |
|
T2V004nn62 |
Seagull | Slow global motion and macroblock tracking with highly reflective background | 00:21:07 |  |
 |
|
T2V004nn63 |
Boat reflection | High reflectivity high contrast | 00:21:08 |  |
 |
|
T2V004nn64 |
Cable car turn | High contrast with tracking of large macroblock areas | 00:50:01 |  |
 |
|
T2V004nn65 |
Streets of San Francisco | Highly erratic ransom global motion and zoom out with line detail and obscured objects | 01:59:17 |  |
 |
|
T2V004nn66 |
Blue boarding | Very rapid pan left with high contrast areas | 00:07:01 |  |
 |
|
T2V004nn67 |
SF silhouette | Slow global zoom with high contrast and over-bright highlights | 00:36:02 |  |
 |
|
T2V004nn68 |
Moneyrail | High contrast bright colors and reflections with text, with slow global motion and large area macroblock motion | 00:50:03 |  |
 |
|
T2V004nn69 |
Chandelier reflections | Macroblock motion vector nightmare (very hard to correlate correct macroblocks) | 00:17:11 |  |
 |
|
T2V004nn70 |
The Real Thing | Slow pan up/down/right with high contrast/high detail and text | 00:44:00 |  |
 |
Show Reel
Please Note: Sequences are provided as high bit rate, full resolution, uncompressed YCbCr.
This show reel is flash compressed to 2 mbit at 854x574, and should not be used to judge the quality of the source material.
 |
 |
 |
| Clip Summary | Scene Features | User Manual Extract |
