3D Europe 2K HD

3D 128
Test how an encoder handles stereoscopic 3D video at 2K resolution and 12-bits per sample, with all aspects of global and local motion, slow/medium/fast motion, with panning, scrolling, zooming, smooth and erratic, high/low contrast, with limited colors/vivid colors and many common subject types, plus different aspects of 3D (different negative & positive disparity, color & luma differences) . Scenes from Europe (Bristol, UK & London) at US frame rates.

T3D003



2D/3D 3D Stereoscopic, Left and Right separate video streams
Description Scenes from Europe (Bristol, UK & London) at US frame rates
Purpose Test how an encoder handles stereoscopic 3D video at 2K resolution and 12-bits per sample, with all aspects of global and local motion, slow/medium/fast motion, with panning, scrolling, zooming, smooth and erratic, high/low contrast, with limited colors/vivid colors and many common subject types, plus different aspects of 3D (different negative & positive disparity, color & luma differences)
Video Format

YUV 4:2:0 planar 8 bits per sample:

1080p stereo

1920x1080, 60fps

Progressive

8-bits per sample

4:2:0

2K stereo

2048x1152, 24fps

Progressive

12-bits per sample

4:2:2

Audio Format

MPEG-1 Layer II stereo 384kbps CBR 16-bit 48kHz and

WAV linear PCM uncompressed stereo 1536kbps 48kHz
Number of Clips 68 Left/Right pairs of individual video clips (34 pairs of sequences at each resolution of 2K and 1920x1080)
Length of Video Total of 38 minutes of paired Left/Right video (19 minutes at each resolution)
Size on Disk 952 GBytes





Why Choose TVids?

TVids were designed both for encoder users (broadcasters, post production, streaming) and for encoder developers, to provide full test coverage of just about any type of video feature that an encoder is likely to encounter, in sequences which you can freely use for demos, trade shows, and on your website.

Every TVid source was captured specifically to cover specific video situations that encoders will encounter.  These situations were then codified in the manual and spreadsheet for each source.  Both content (animals, people, buildings) and challenges (angles, banding, focus, panning, patterns) are listed for easy searching when detecting problems, or finding clips to challenge particular parts of the encoder.

All TVids were captured at the highest possible resolution, bit depth and frame rate.  Lower resolution and frame rate versions were carefully created from the higher frame rate and resolution, providing the best possible quality.  This also means the same tests can be made against equipment and software running at different frame rates and sizes (e.g. 1080, 720 and SD).

TVids provide the most complete suite of test video, that are uncompressed, high bit depth, high frame rate and well documented in the industry.  TVids also provide a liberal multiple use in house and full use of exported/converted video and audio, with no worry about media and display rights internationally.

TestVid Tools

To get the most out of your TestVid test clips, TestVid has all the tools you need to display, convert and output your test material, test patterns and even other test material sources.  All TestVid material is shipped in the highest possible quality, and can be read by a number of third party software products. These tools provide guaranteed high quality viewing and conversion to formats that are compatible with almost all off-the-shelf software.

TestVid Reactor

TestVid Reactor is a dedicated tool that supports lossless conversion to uncompressed types and high quality conversion to compressed formats.  Direct high bit depth YCbCr conversion from the original material to MOV, AVI, YUV, V210, DPX or MXF means every possible bit is preserved in a perfectly compatible format. Compressed outputs like XDCam, AVCi (optional), ProRes and DNxHD (optional) are also available for maximum display compatibility.  Selectable timecode burn in and audio/video frame sync pulses adds further flexibility to the test media and test pattern output.

For more information, click here.

TestVid Pro Player

TestVid Pro Player provides 10 bit YCbCr to DVI, HDMI and HD-SDI using your AJA, BlueFish444 or Blackmagic video card, under Windows or OS-X. This player supports both the native, high bit depth raw file format or the test videos and patterns, as well as most standard scientific, post production and broadcast file formats.  YUV, AVI, MOV, MXF, DPX, HDR/Raw and even MPEG-2, MPEG-4, h.264 and internet file types can be be played.  Raw data (decimal/hex view), histogram, waveform monitors, vectorscope, and full screen DVI modes are included.

For more information, click here.

Special Limited Time Offer

For a limited time, both the TestVid Reactor and TestVid Pro Player are available bundled with any T2V (SD, HD, 2K and 4K test media) or T3D (3D 4K, 2K or HD) media set.  One full feature license of both products will be included, with full support and updates for one year.  Since we are including the TestVid Tools for free, if you need to license the AVCi and DNxHD codecs they are optional. Please note, this is a limited time offer.

TestVid Extras

Test Pattern Set - All TestVid test media packages include TestVid's Test Pattern set.  The test pattern set includes over 100 test patterns for each video standard, including 4K, 2K, HD 1080, 720, SD PAL and SD NTSC.  Audio files with calibrated Peak/RMS, EBU.128/1195 loudness, channel IDs and standard waveforms are also included.  All patterns are 10 bit YCbCr frames, and up to 24 bit audio at 48000 Hz.

Test Pattern File Generator - Included with the test pattern source files is the TVid Test Pattern File Generator.  This software allows the single frame patterns and audio to be combined into MXF, MOV, AVI and other standard files for use in testing, editing and calibration.  The pattern files are also fully compatible with the included TestVid Pro Player for immediate HDMI, HD-SDI or DVI output, and TestVid Reactor for conversion to AVI, MOV, DPX, YUV, and MXF. This pattern system is also available separately for 99$ USD.

Clip Summary

Clip IDTitleMain PurposeDurationBeginEnd

T3D003001

Silver_dome

General 3D view of complex scene, static background

00:39:56



T3D003002

PedXing

3D view with detailed background and short duration peak negative disparity

00:34:42



T3D003003

Ice_cream_van

3D effect with global motion and transitory large negative disparity

00:36:32



T3D003004

Cafe_by_docks

Depth perception with multiple curved shiny objects (metal chairs)

00:34:06



T3D003005

Ferry_arrives

Low depth subject and background but depth perception on water

00:33:02



T3D003006

Big_Ben

Multiple crossing movement close to camera with detailed objects a long way away

00:26:48



T3D003007

Suspension_br

Initially mild 3D effect of man-made structures changes to much stronger 3D effect of trees, with fade/transition

00:37:43



T3D003008

Traffic_twds

3D perception of objects rapidly approaching the cameras, passing close

00:36:42



T3D003009

Cabot_Tower

Effect on 3D perception with random movement (including rotation), irregular foreground (grass) man-made structure and largely monochrome blue sky

00:51:10



T3D003010

Shopping_mall

3D effects starts strongly, becomes much milder with detailed and contrasting scene, ending more strongly also

00:41:29



T3D003011

Train_comes _n_goes

3D perception with fade/transition and short zoom

00:34:48



T3D003012

Pool_shark

'Codec and 3D perception nightmare', where motion vector tracking is not possible and it is impossible to judge the depth of the majority of the scene and objects seem to be floating (which of course they are)

00:28:42



T3D003013

Centre_fast

Effect on 3D perception of very rapid movement causing motion blur

00:12:19



T3D003014

Soccer

Effect on 3D perception with evident differences caused by lens differences

00:24:53



T3D003015

Blaise_woods

Random movement (including rotation) where most of the scene looks very similar); global motion but little subject motion

00:41:43



T3D003016

Duck_truck

3D perception with noticeable color differences

00:38:06



T3D003017

St_Pauls

Perception where object with strong 3D effect is very close to the cameras and leads into the scene

00:23:58



T3D003018

Waterfall

Largely static shot but sunlit waterfall causes different views in left & right

00:45:01



T3D003019

Portents

Mild 3D effect but clearly distanced layers of elements (the 'tents')

00:22:57



T3D003020

Street_ performer

Perception of 3D when there are significant window violations at both sides

00:36:03



T3D003021

Footbridge

Perception of 3D when the moving subjects (the people) are substantially obscured

00:55:33



T3D003022

Fountains

3D perception with smoothly changing angle

01:13:00



T3D003023

Mall_at_night

3D perception where subjects are dark and edges not easily distinguishable from the background for much of the time

00:44:39



T3D003024

Musical_reflections

Effect on 3D when much of the scene is either at different angles or distorted geometry or both

00:35:41



T3D003025

Suspension_br _zoom

Example of problems with zooming when using 'identical' lenses

00:21:46



T3D003026

Garden

General 3D view with substantial detail and movement (including rotation)

00:19:46



T3D003027

Balloons

Illustration of issues when interocular far too wide for subject distance (i.e. people walking past close to camera, although the balloons are OK to view)

00:15:12



T3D003028

The_Matthew

General 3D view of complex scene, with smooth scrolling and panning

00:43:39



T3D003029

Falafel_King

Complex scene where camera movement is random and jerky, and objects are distances from very close to the camera to far away

00:16:21



T3D003030

String_quartet

Medium 3D effect but hand-held camera movement

00:27:02



T3D003031

Number_7_boat

Very mild 3D effect

00:19:32



T3D003032

Night_cars

3D effect with substantial lens flare and high contrast, plus fast approach to/going away from cameras

00:33:12



T3D003033

Follow_that_ ship

General 3D view with hand-held camera and complex scene

00:13:13



T3D003034

Roundabout

Generally medium 3D but effect of transitory excessive negative disparity

00:50:39



T3D003101

Silver_dome

General 3D view of complex scene, static background

00:39:56



T3D003102

PedXing

3D view with detailed background and short duration peak negative disparity

00:34:42

 T3D003102 start  T3D003102 end
T3D003103 Tightrope Viewer acceptability with excessive peak negative disparity on small part of picture 00:36:32  T3D003103 start  T3D003103 end
T3D003104 Dockyard_cafe Depth perception with multiple curved shiny objects (metal chairs) 00:34:06  T3D003104 start  T3D003104 end
T3D003105 Ferry_arrives Low depth subject and background but depth perception on water 00:33:02  T3D003105 start  T3D003105 end
T3D003106 Big_Ben Multiple crossing movement close to camera with detailed objects a long way away 00:26:48  T3D003106 start  T3D003106 end
T3D003107 Suspension_Br Initially mild 3D effect of man-made structures changes to much stronger 3D effect of trees, with fade/transition 00:37:43  T3D003107 start  T3D003107 end
T3D003108 Traffic_twds 3D perception of objects rapidly approaching the camera, passing close 00:36:42  T3D003108 start  T3D003108 end
T3D003109 Cabot_Tower Effect on 3D perception with random movement (including rotation), irregular foreground (grass), man-made structure and largely monochrome blue sky 00:51:10  T3D003109 start  T3D003109 end
T3D003110 Shopping_mall 3D effect starts strongly, becomes much milder with detailed and contrasting scene, ending more strongly also 00:41:29  T3D003110 start  T3D003110 end
T3D003111 Night_crossing Effect on 3D of dark grainy video 00:34:48  T3D003111 start  T3D003111 end
T3D003112 Pool_shark Codec and 3D perception nightmare, where motion vector tracking is not possible and it is impossible to judge the depth of the majority of the scene and objects seem to be floating (which of course they are) 00:28:42  T3D003112 start  T3D003112 end
T3D003113 Centre_fast Effect on 3D perception with very fast movement causing motion blur 00:12:19  T3D003113 start  T3D003113 end
T3D003114 Dockside_cottages High contrast scene with pan and fade/transition - global motion but very little subject motion 00:24:53  T3D003114 start  T3D003114 end
T3D003115 Blaise_woods Random movement (including rotation) where most of the scene looks very similar; global motion but little subject motion 00:41:43  T3D003115 start  T3D003115 end
T3D003116 Big_airplane Effect on 3D of substantial color difference between left & right 00:38:06  T3D003116 start  T3D003116 end
T3D003117 St_Pauls Perception where object with strong 3D effect is very close to the cameras and leads into the scene 00:23:58  T3D003117 start  T3D003117 end
T3D003118 Waterfall Largely static shot but sunlit waterfall causes different views in left & right 00:45:01  T3D003118 start  T3D003118 end
T3D003119 Portents Mild 3D effect but clearly distanced layers of elements (the 'tents') 00:22:57  T3D003119 start  T3D003119 end
T3D003120 Pink_hat Limited global movement but occasionally subjects close to the cameras 00:36:03  T3D003120 start  T3D003120 end
T3D003121 Footbridge Perception of 3D where the moving subjects (the people) are substantially obscured 00:55:33  T3D003121 start  T3D003121 end
T3D003122 Fountains Perception of 3D with very clear 2D depth clues 01:13:00  T3D003122 start  T3D003122 end
T3D003123 Boat_out 3D effect when many reflections appear only in left or right 00:44:39  T3D003123 start  T3D003123 end
T3D003124 Musical_reflections Effect on 3D when much of the scene is either at different angles or distorted geometry or both. Note: audio has music 00:35:41  T3D003124 start  T3D003124 end
T3D003125 Suspension_br_zoom Example of problems with zooming when using 'identical' lenses 00:21:46  T3D003125 start  T3D003125 end
T3D003126 Garden General 3D view with substantial detail and movement (including rotation 00:19:46  T3D003126 start  T3D003126 end
T3D003127 Purple_pillars Effect on 3D perception with grainy dark view and panning movement 00:15:11  T3D003127 start  T3D003127 end
T3D003128 The_Matthew General 3D view of complex scene with smooth scrolling and panning movement 00:43:49  T3D003128 start  T3D003128 end
T3D003129 Falafel_King Complex scene where camera movement is random and jerky, and objects are distances from very close to the camera to far away, and the screen plane is frequently adjusted during the sequence 00:16:21  T3D003129 start  T3D003129 end
T3D003130 String_quartet Medium 3D effect but hand-held camera movement. Note: audio has music 00:27:02  T3D003130 start  T3D003130 end
T3D003131 Water_taxi Very mild 3D effect 00:19:32  T3D003131 start  T3D003131 end
T3D003132 Night_cars 3D effect with substantial lens flare and high contrast, plus fast approach to/going away from cameras 00:33:12  T3D003132 start  T3D003132 end
T3D003133 Blue_building 3D depth confusion possible with multiple internal reflections and surfaces 00:13:13  T3D003133 start  T3D003133 end
T3D003134 Dancers Medium 3D effect with some global motion and subject motion 00:50:39  T3D003134 start  T3D003134 end





T3D003 Demo Reel

(Note: Reduced resolution and compressed.  Original

supplied files are full resolution and uncompressed)
